D4C0112S

Electroswitch
RoHS
RoHS RoHS compliant
Package /
Category Switches / Rotary Switches
Description Switch, Rotary;1 Pole;2-12 Pos.;1 Sec.;Ceramic Ins.;Shorting;1.5A;28VDC;Solder T.
PDF
/
Buying Options
Total Price: USD $53.73
Unit Price: USD $53.729277
≥1 USD $53.729277
≥10 USD $50.687999
≥100 USD $47.81886
≥500 USD $45.112143
≥1000 USD $42.558623
Inventory: 1187
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Actuator Length 47.63mm

Technical

Angle of Throw 30°
Number of Poles per Deck 1
Index Angle 30 °
Depth Behind Panel 14.76mm
Circuit per Deck SP12T
Index Stops Adjustable
Contact Timing Shorting (MBB)
Number of Decks 1
Mechanical Life 25000 cycles
Max Voltage Rating (DC) 28V
Throw Configuration SP12T
Number of Poles 1
Max Voltage Rating (AC) 115V
Contact Resistance 3.5mOhm
Contact Style Shorting
Panel Cutout Dimensions Circular - 9.78mm Dia
Actuator Type Round (6.35mm Dia)
Voltage - Rated AC 115V
Termination Style Solder Lug
Contact Finish Silver
Current Rating 1.5A
Depth 14.7574mm
Orientation Straight
Current Rating (Amps) 500mA AC 1.5A DC
Voltage - Rated DC 28V
Number of Positions 2 ~ 12
Termination Solder
Part Status Active
Series D4
Published 2006

Physical

Insulation Material Ceramic
Mounting Type Panel Mount
Mount Panel
Contact Plating Silver
Contact Material Brass

Supply Chain

Factory Lead Time 5 Weeks
