RTBV21BS16AG0ZP

C&K
RoHS
/
Package /
Category Switches / Rotary Switches
Description SWITCH ROTARY 16POS 20MA 25V
PDF
/
Inventory: 7789
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Actuator Length 16.00mm

Technical

Angle of Throw 22.5°
Index Angle 22.5 °
Depth Behind Panel 10.65mm
Circuit per Deck BCD
Index Stops Fixed
Contact Timing Non-Shorting (BBM)
Operating Force 5.099gfm
Number of Decks 1
Contact Style Non-Shorting
Panel Cutout Dimensions Circular - 9.73mm Dia
Actuator Type Flatted (6.35mm Dia)
Voltage - Rated AC 25V
Termination Style PC Pin
Contact Finish Gold
Current Rating 20mA
Current Rating (Amps) 20mA AC/DC
Voltage - Rated DC 25V
Number of Positions 16
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Sealed - Fully
Series RTBV
Published 2010

Physical

Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Plating Gold
Contact Material Brass
