A40342MNZB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
Switch Rotary N.O./N.C. 4P3T 3 Metric Shaft Solder Lug 20VAC 20VDC 0.4VA Automotive
PDF
/
Buying Options
Total Price: USD $33.15
Unit Price: USD $33.154664
≥1 USD $33.154664
Inventory: 1464
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length 42.00mm
Length 26.19mm
Technical
Angle of Throw 30°
Number of Poles per Deck 4
Index Angle 30 °
Depth Behind Panel 20.83mm
Circuit per Deck 4P3T
Index Stops Fixed
Contact Timing Non-Shorting (BBM)
Number of Decks 1
Max Voltage Rating (DC) 20V
Throw Configuration 4P3T
Electrical Life 300000 cycles
Max Voltage Rating (AC) 20V
Contact Style Non-Shorting
Panel Cutout Dimensions Circular - 10.21mm Dia
Actuator Type Round (6mm Dia)
Voltage - Rated AC 20V
Termination Style Solder Lug
Contact Finish Gold
Depth 26.19mm
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Positions 3
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series A
Published 2010
Physical
Actuator Material Glass, Nylon
Housing Material Nylon
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
