SRD1-1B-DC-1-BRN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Convex (Reverse V) - Illuminated SRD1 Black Panel Mount Snap-In Rocker Switch 21A DC 14V -25C~85C
PDF
/
Inventory: 8907
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Panel Mount, Snap-In
Technical
Operating Temperature -25°C~85°C
Series SRD1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 14V
Current Rating (Amps) 21A DC
Ingress Protection IP56 - Dust Protected, Water Resistant
Termination Style Quick Connect - 0.250 (6.3mm)
Actuator Type Convex (Reverse V) - Illuminated
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Rectangular - 36.80mm x 21.20mm
Color - Actuator/Cap Black
Illumination Type, Color LED, Red
Electrical Life 6,000 Cycles
Mechanical Life 10,000 Cycles
Actuator Marking No Marking
Compliance
RoHS Status ROHS3 Compliant
