47ASP3R1M2RT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Standard V) 47A Black Panel Mount Flange Rocker Switch 9.56mm 0.02A 20V .02A@20VAC
PDF
/
Inventory: 2255
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Body Height 9.56mm
Length 29.36mm
Technical
Actuator Marking No Marking
Contact (DC) Max Rating R Load .02A@20VDC
Contact (AC) Max Rating R Load .02A@20VAC
Contact Current(AC)-Max 0.02A
Switch Type ROCKER SWITCH
Max Voltage Rating (DC) 20V
Electrical Life 40,000 Cycles
Max Voltage Rating (AC) 20V
Contact Current(DC)-Max 0.02A
Color - Actuator/Cap Black
Switch Function On-Off-On
Circuit SPDT
Actuator Type Concave (Standard V)
Body Breadth 6.86 mm
Voltage - Rated AC 20V
Termination Style PC Pin
Depth 9.27mm
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
HTS Code 8536.50.90.65
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e4
Series 47A
Published 2010
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Through Hole
Contact Plating Gold
Contact Material Brass
Supply Chain
Factory Lead Time 18 Weeks
