RB141C1000-144
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPST 15A 125V
PDF
/
Buying Options
Total Price: USD $2.28
Unit Price: USD $2.277882
≥1 USD $2.277882
≥250 USD $0.90984
≥500 USD $0.879643
≥1000 USD $0.863888
Inventory: 6046
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.343 inch
Length - Termination 0.394 inch
Body Height 16.6878mm
Technical
Body Color BLACK
Contact Function OFF-ON
Actuator Marking No Marking
Contact Voltage(AC)-Max 125V
Contact Current(AC)-Max 15A
Switch Type ROCKER SWITCH
Electrical Life 10,000 Cycles
Dielectric Withstanding Voltage 1500VAC V
Illumination Type, Color Incandescent, Blue
Illumination Voltage (Nominal) 12VDC
Color - Actuator/Cap Blue
Insulation Resistance 100000000Ohm
Contact Resistance 0.035mOhm
Panel Cutout Dimensions Rectangular - 30.00mm x 11.00mm
Switch Function On-Off
Circuit SPST
Actuator Type Concave (Curved) - Illuminated
Body Breadth 10.8966 mm
Body Length or Diameter 27.2034mm
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating (Amps) 15A AC
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series RB1, LAMB
Published 2012
Packaging Bulk
Operating Temperature -20°C~65°C
Physical
End Contact Plating SILVER
End Contact Material COPPER
Center Contact Material COPPER
Center Contact Plating SILVER
Actuator Material POLYCARBONATE
Insulation Material POLYAMIDE
Surface Mount NO
Mounting Type Panel Mount, Snap-In
