RA111C1021-124
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPST 16A 125V
PDF
/
Inventory: 2353
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Insulation Material POLYAMIDE
Actuator Material POLYCARBONATE
Center Contact Material SILVER ALLOY
End Contact Material SILVER ALLOY
Technical
Operating Temperature -20°C~55°C
Packaging Bulk
Series RA1, LAMB
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Current Rating (Amps) 16A AC
Current Rating 16A
Termination Style Quick Connect - 0.187 (4.7mm)
Voltage - Rated AC 125V
Body Length or Diameter 18.4912mm
Body Breadth 12.9032 mm
Actuator Type Concave (Curved) - Illuminated
Circuit SPST
Switch Function On-Off
Panel Cutout Dimensions Rectangular - 19.40mm x 13.10mm
Contact Resistance 0.035mOhm
Insulation Resistance 100000000Ohm
Color - Actuator/Cap Amber
Illumination Voltage (Nominal) 12VDC
Illumination Type, Color Incandescent, Amber
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 10,000 Cycles
Switch Type ROCKER SWITCH
Contact (AC) Max Rating R Load 16A@125VAC
Actuator Marking O -
Contact Function OFF-ON
Body Color BLACK
Contact (AC) Max Power Rating R Load 0.3HP@250VAC
Dimensions
Body Height 13.3096mm
Length - Termination 0.271 inch
Actuator Length 0.236 inch
Compliance
RoHS Status ROHS3 Compliant
