R1966ABLKGRYEPGRN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPST 15A 125V
PDF
/
Inventory: 6647
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Insulation Material NYLON
Actuator Material POLYCARBONATE
Center Contact Plating SILVER
Center Contact Material COIN SILVER
Terminal Material COPPER ALLOY
End Contact Material COIN SILVER
End Contact Plating SILVER
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Body Color BLACK
PCB Hole Count 5
Actuator Marking No Marking
Contact Voltage(AC)-Max 250V
Contact Timing SNAP ACTION
Contact (AC) Max Rating R Load 6A@250VAC
Contact Current(AC)-Max 6A
Illumination Type LED
Switch Type ROCKER SWITCH
Mechanical Life 30,000 Cycles
Electrical Life 10,000 Cycles
Sealing MOLDED
Illumination Type, Color LED, Green
Illumination Voltage (Nominal) 2.2VDC
Color - Actuator/Cap Gray
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Rectangular - 19.40mm x 13.00mm
Switch Function On-Off
Circuit SPST
Actuator Type Concave (Curved) - Illuminated
Body Breadth 13.0048 mm
Body Length or Diameter 18.5928mm
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 15A
Current Rating (Amps) 15A AC
Additional Feature SNAP-IN TYPE PANEL MOUNTING
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series R1966
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.217 inch
Length - Termination 0.11 inch
Body Height 13.0048mm
