300SP3R2BLKM2QE

E-Switch
RoHS
RoHS RoHS compliant
Package /
Category Switches / Rocker Switches
Description SWITCH ROCKER SPDT 5A 120V
PDF
/
Inventory: 3160
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Contact Plating Silver
Mount Flanges, Panel
Mounting Type Panel Mount, Flange
Housing Material Stainless Steel
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
End Contact Material COPPER ALLOY

Technical

Operating Temperature -30°C~85°C
Packaging Bulk
Series 300
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Body Breadth 6.858 mm
Actuator Type Paddle
Circuit SPDT
Switch Function On-Off-On
Panel Cutout Dimensions Rectangular - 17.96mm x 10.62mm
Contact Resistance 0.01mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap Black
Contact Current(DC)-Max 5A
Dielectric Withstanding Voltage 1000VRMS V
Electrical Life 40,000 Cycles
Switch Type TOGGLE SWITCH
Contact Current(AC)-Max 2A
Contact (AC) Max Rating R Load 2A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Marking No Marking
Actuator Angle 25 deg

Dimensions

Body Height 8.8392mm
Actuator Length 0.885 inch

Compliance

RoHS Status ROHS3 Compliant
