3003P1R16BLKM1QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER 3PDT 5A 120V
PDF
/
Inventory: 1766
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Actuator Marking No Marking
Electrical Life 40,000 Cycles
Color - Actuator/Cap Black
Panel Cutout Dimensions Rectangular - 12.78mm x 12.52mm
Switch Function On-On
Circuit 3PDT
Actuator Type Paddle
Voltage - Rated AC 120V
Termination Style Solder Lug
Current Rating 5A
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 300
Published 2015
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Housing Material Stainless Steel
Mounting Type Panel Mount, Flange
Mount Flanges, Panel
Contact Plating Silver
Supply Chain
Factory Lead Time 9 Weeks
