U211J61ZQI22

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Rocker Switches
Description Switch Rocker ON ON ON SP3T Solder Lug Lever 5A 250VAC 28VDC
PDF
/
Buying Options
Total Price: USD $29.68
Unit Price: USD $29.675479
≥1 USD $29.675479
Inventory: 1780
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Length 19.43mm

Technical

Actuator Marking No Marking
Max Voltage Rating (DC) 28V
Throw Configuration DPDT, SP3T
Electrical Life 40,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Black
Panel Cutout Dimensions Rectangular - 15.24mm x 12.70mm
Switch Function On-On-On
Circuit SP3T
Actuator Type Paddle
Voltage - Rated AC 120V
Termination Style Solder Lug
Current Rating 5A
Depth 15.62mm
Orientation Straight
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Jumper needed to achieve triple throw
Series 7000
Published 2010
Packaging Bulk
Operating Temperature -30°C~85°C

Physical

Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Silver
Contact Material Silver

Supply Chain

Factory Lead Time 14 Weeks
