E201J1V3QE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Rocker Switches ROCKER SWITCH STRAIGHTDPDTON-ON
PDF
/
Buying Options
Total Price: USD $15.96
Unit Price: USD $15.9632
≥1 USD $15.9632
≥10 USD $14.498
≥100 USD $13.11332
≥500 USD $12.6247
≥1000 USD $11.810198
≥3000 USD $10.0804
Inventory: 90
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 16.87mm
Technical
Actuator Marking No Marking
Illumination Type Illuminated
Max Voltage Rating (DC) 28V
Electrical Life 40,000 Cycles
Max Current Rating 7.5A
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Black
Switch Function On-On
Circuit DPDT
Actuator Type Concave (Standard V)
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 7.5A
Depth 11.43mm
Orientation Straight
Current Rating (Amps) 7.5A AC/DC
Voltage - Rated DC 28V
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Sealed - Flux Protection
Series E
Published 2016
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Mounting Type Through Hole
Mount Brackets, Through Hole
Contact Material Silver
Supply Chain
Factory Lead Time 16 Weeks
