D202J12S215DQA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Switch Rocker ON None OFF DPST Quick Connect Curved Rocker 4A 250VAC 30VDC
PDF
/
Buying Options
Total Price: USD $7.06
Unit Price: USD $7.060776
≥1 USD $7.060776
Inventory: 5044
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper
Contact Plating Silver
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Housing Material Nylon
Actuator Material Nylon
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Published 2014
Series D
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Max Operating Temperature 65°C
Min Operating Temperature -30°C
Current Rating (Amps) 4A AC
Orientation Straight
Depth 23.85mm
Current Rating 4A
Termination Style Quick Connect - 0.187 (4.7mm)
Voltage - Rated AC 125V
Actuator Type Concave (Curved)
Housing Color Black
Circuit DPST
Switch Function On-Off
Panel Cutout Dimensions Rectangular - 22.53mm x 19.20mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 4A
Electrical Life 10,000 Cycles
Throw Configuration DPST
Max Voltage Rating (DC) 30V
Actuator Marking ON OFF, Vertical
Dimensions
Length 20.83mm
Compliance
RoHS Status ROHS3 Compliant
