CL101J72S205QA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 16A 125V
PDF
/
Buying Options
Total Price: USD $2.11
Unit Price: USD $2.112
≥1 USD $2.112
≥10 USD $1.89112
≥100 USD $1.794496
≥500 USD $1.706672
≥1000 USD $1.627472
≥3000 USD $1.557107
Inventory: 929
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Silver
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Actuator Material Nylon
Technical
Operating Temperature -20°C~80°C
Packaging Bulk
Published 2010
Series CL
Feature Positive Detent
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Current Rating (Amps) 16A AC
Orientation Straight
Depth 17.2mm
Current Rating 16A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Actuator Type Concave (Standard V)
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Rectangular - 28.80mm x 14.00mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 16A
Electrical Life 10,000 Cycles
Actuator Marking No Marking
Dimensions
Length 31.8mm
Width 13.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
