7301J60V2GE3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER 3PDT 5A 120V
PDF
/
Inventory: 6931
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Gold
Mount Brackets, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Depth 16.51mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Paddle
Circuit 3PDT
Switch Function On-On
Color - Actuator/Cap Red
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 100,000 Cycles
Throw Configuration 3PDT
Max Voltage Rating (DC) 28V
Actuator Marking No Marking
Dimensions
Length 19.56mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
