7301J37CBE22
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER 3PDT 0.4VA 20V
PDF
/
Inventory: 1603
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 37.44mm
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 20V
Throw Configuration 3PDT
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Color - Actuator/Cap Black
Panel Cutout Dimensions Rectangular - 30.99mm x 17.15mm
Switch Function On-On
Circuit 3PDT
Actuator Type Concave (Standard V)
Voltage - Rated AC 20V
Termination Style PC Pin
Depth 24.56mm
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2010
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in, Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 14 Weeks
