7301J1V2QE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER 3PDT 5A 120V
PDF
/
Inventory: 6710
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 19.56mm
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 28V
Electrical Life 100,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Black
Switch Function On-On
Circuit 3PDT
Actuator Type Concave (Standard V)
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 5A
Depth 16.51mm
Orientation Straight
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2015
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Through Hole
Mount Brackets, Through Hole
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
