7215J91CQE22
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Paddle 7000 Black Panel Mount Snap-In Rocker Switch 15.62mm 5A 250V -30C~85C
PDF
/
Inventory: 8617
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Silver
Mount Panel, Snap in, Through Hole
Mounting Type Panel Mount, Snap-In
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Series 7000
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Depth 15.62mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Paddle
Circuit SP3T
Switch Function Mom-On-Mom
Panel Cutout Dimensions Rectangular - 15.24mm x 12.70mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 40,000 Cycles
Throw Configuration DPDT, SP3T
Max Voltage Rating (DC) 28V
Actuator Marking No Marking
Dimensions
Length 19.43mm
Compliance
RoHS Status ROHS3 Compliant
