7213J1ZBE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Standard V) 7000 Black Panel Mount Flange Rocker Switch 11.43mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 5410
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Plating Gold
Mount Flanges, Panel
Mounting Type Panel Mount, Flange
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2016
Series 7000
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Depth 11.43mm
Termination Style Solder Lug
Voltage - Rated AC 20V
Actuator Type Concave (Standard V)
Circuit SP3T
Switch Function On-On-Mom
Panel Cutout Dimensions Rectangular - 17.96mm x 10.62mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 20V
Electrical Life 40,000 Cycles
Throw Configuration DPDT, SP3T
Max Voltage Rating (DC) 20V
Actuator Marking No Marking
Dimensions
Length 29.36mm
Compliance
RoHS Status ROHS3 Compliant
