7207J3CGE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Switch Rocker ON OFF Mom DPDT PC Pins Long Rocker 5A 250VAC 28VDC 0.4VA
PDF
/
Inventory: 4102
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Gold
Mount Panel, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2016
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Depth 15.11mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Concave (Standard V)
Circuit DPDT
Switch Function On-Off-Mom
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 40,000 Cycles
Throw Configuration DPDT
Max Voltage Rating (DC) 28V
Actuator Marking No Marking
Dimensions
Length 41.28mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
