7201J3V61BE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Standard V) 7000 Black Through Hole Rocker Switch 15.11mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 4843
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Plating Gold
Mount Brackets, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2010
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Straight
Depth 15.11mm
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Concave (Standard V)
Circuit DPDT
Switch Function On-On
Color - Actuator/Cap Black
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration DPDT
Max Voltage Rating (DC) 20V
Actuator Marking No Marking
Dimensions
Length 26.8mm
Compliance
RoHS Status ROHS3 Compliant
