7201J1A3BE1

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Rocker Switches
Description Concave (Standard V) 7000 White Through Hole Right Angle Rocker Switch 29.03mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 4112
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Throw Configuration DPDT
Max Voltage Rating (DC) 20V
Actuator Marking No Marking
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Color - Actuator/Cap White
Switch Function On-On
Circuit DPDT
Actuator Type Concave (Standard V)
Voltage - Rated AC 20V
Termination Style PC Pin
Depth 29.03mm
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2008
Packaging Bulk
Operating Temperature -30°C~85°C

Dimensions

Length 16.87mm

Compliance

RoHS Status ROHS3 Compliant

Physical

Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Plating Gold

Supply Chain

Factory Lead Time 14 Weeks
