7109J1AV2BE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Standard V) 7000 Black Through Hole Right Angle Vertical Rocker Switch 34.26mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Inventory: 2950
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Plating Gold
Mount Brackets, Through Hole, Vertical
Mounting Type Through Hole, Right Angle, Vertical
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2008
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Depth 34.26mm
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Concave (Standard V)
Circuit SPDT
Switch Function On-Mom
Color - Actuator/Cap Black
Max Voltage Rating (AC) 20V
Electrical Life 40,000 Cycles
Throw Configuration SPDT
Max Voltage Rating (DC) 20V
Actuator Marking No Marking
Dimensions
Length 9.27mm
Compliance
RoHS Status ROHS3 Compliant
