7101J2WBE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 0.4VA 20V
PDF
/
Inventory: 3320
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Plating Gold
Mount Flanges, Panel
Mounting Type Panel Mount, Flange
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2010
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Depth 9.27mm
Termination Style Wire Wrap
Voltage - Rated AC 20V
Actuator Type Paddle
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Rectangular - 17.96mm x 10.62mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration SPDT
Max Voltage Rating (DC) 20V
Actuator Marking No Marking
Dimensions
Length 29.36mm
Compliance
RoHS Status ROHS3 Compliant
