C1353AABG2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER DPST 20A 250V
PDF
/
Buying Options
Total Price: USD $7.72
Unit Price: USD $7.7176
≥1 USD $7.7176
≥10 USD $6.97488
≥100 USD $6.639424
≥500 USD $6.566912
Inventory: 703
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.299 inch
Length - Termination 0.358 inch
Technical
Contact (AC) Max Power Rating R Load 0.5HP@125VAC
Body Color BLACK
Actuator Marking No Marking
Contact Voltage(AC)-Max 250V
Contact Current(AC)-Max 20A
Switch Type ROCKER SWITCH
Contact Voltage(DC)-Max 24V
Illumination Type, Color Neon, Green
Illumination Voltage (Nominal) 125VAC
Contact Current(DC)-Max 20A
Color - Actuator/Cap Green
Insulation Resistance 20000000Ohm
Contact Resistance 0.1mOhm
Panel Cutout Dimensions Rectangular - 27.30mm x 22.40mm
Switch Function On-Off
Circuit DPST
Actuator Type Concave (Curved) - Illuminated
Voltage - Rated AC 250V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating (Amps) 20A AC/DC
Voltage - Rated DC 24V
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 1350
Packaging Bulk
Physical
End Contact Material SILVER ALLOY
Center Contact Material SILVER ALLOY
Actuator Material POLYCARBONATE
Insulation Material NYLON
Surface Mount NO
Mounting Type Panel Mount, Snap-In
Supply Chain
Factory Lead Time 24 Weeks
