BH1417FV-E2
RoHS
RoHS compliant
RoHS compliantPackage 24-LSSOP (0.220, 5.60mm Width)
Category RF/IF and RFID / RF Transmitters
Description
RF XMITTER FM 76-90MHZ 24LSSOP
PDF
/
Buying Options
Total Price: USD $0.98
Unit Price: USD $0.9823
≥1 USD $0.9823
≥10 USD $0.8056
≥100 USD $0.7809
≥500 USD $0.75525
≥1000 USD $0.73055
Inventory: 1512
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.15mm
Width 5.6mm
Length 7.8mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol FM
Current - Transmitting 20mA
Power - Output -7dBm
Data Interface PCB, Surface Mount
Nominal Supply Current 21mA
Power Supplies 5V
Qualification Status Not Qualified
Frequency 76MHz~90MHz 87.5MHz~108MHz
Terminal Pitch 0.635mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4V~6V
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Applications Wireless Audio Link LSI
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-LSSOP (0.220, 5.60mm Width)
