AX5031-1-TA05
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transmitters
Description
RADIO TRANSMITTER
PDF
/
Inventory: 5978
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 1mm
Technical
Antenna Connector Castellation
Modulation or Protocol ISM
Current - Transmitting 44mA
Data Rate (Max) 2Mbps
Power - Output 15dBm
Telecom IC Type TELECOM CIRCUIT
Data Interface SPI
Frequency 400MHz~470MHz 800MHz~940MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.2V~3.6V
Technology CMOS
Applications General Purpose
Terminal Finish Tin (Sn)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 20
Package / Case 20-VFQFN Exposed Pad
Mount Surface Mount
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Factory Lead Time 14 Weeks
