ATA8741-PXQW
RoHS
RoHS compliant
RoHS compliantPackage 24-VQFN Exposed Pad
Category RF/IF and RFID / RF Transmitters
Description
MCU W/TRANSMITTER ASK/FSK 24QFN
PDF
/
Buying Options
Total Price: USD $22.84
Unit Price: USD $22.83515
≥1 USD $22.83515
≥10 USD $18.7359
≥100 USD $18.1507
≥500 USD $17.5655
≥1000 USD $16.97935
Inventory: 12006
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 5mm
Height Seated (Max) 1mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol ASK, FSK
Current - Transmitting 9.8mA
Data Rate (Max) 32kbps
Power - Output 8dBm
Number of Programmable I/O 12
Core Architecture AVR
Number of Timers/Counters 2
Data Interface PCB, Surface Mount
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Bit Size 8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Memory Type FLASH
RAM Size 256B
Speed 16 MHz
Number of I/O 12
Memory Size 4kB Flash 256B EEPROM 256B SRAM
Interface SPI
Frequency 310MHz~350MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2V~4V
Technology CMOS
Max Power Dissipation 100mW
Applications Home Automation, Remote Sensing, RKE
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 24
Package / Case 24-VQFN Exposed Pad
Mount Surface Mount
