ATSAMW25H18-MR210PB1944
RoHS
RoHS compliant
RoHS compliantPackage Module
Category RF/IF and RFID / RF Transceiver Modules
Description
SMARTCONNECT MODULE
PDF
/
Inventory: 7422
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 14.908mm
Length 33.864mm
Height Seated (Max) 2.138mm
Technical
Firmware Version 19.4.4
Current - Transmitting 172mA
Current - Receiving 70mA
Serial Interfaces SPI, UART
Sensitivity -98dBm
Antenna Type Integrated, Trace
RF Family/Standard WiFi
Power - Output 17dBm
Telecom IC Type TELECOM CIRCUIT
Protocol 802.11b/g/n
Data Rate 72Mbps
Memory Size 256kB Flash 32kB SRAM
JESD-30 Code R-XXMA-N51
Base Part Number ATSAMW25
Frequency 2.4GHz~2.48GHz
Terminal Pitch 1.2mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position UNSPECIFIED
Voltage - Supply 2.7V~4.3V
Number of Terminations 51
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case Module
Mounting Type Surface Mount
