ATBTLC1000-ZR110CA
RoHS
RoHS compliant
RoHS compliantPackage Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MOD BLUETOOTH CHIP ANT
PDF
/
Inventory: 3352
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mounting Type Surface Mount
Package / Case Module
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2016
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 35
Voltage - Supply 1.8V~4.3V
Terminal Position UNSPECIFIED
Terminal Form NO LEAD
Number of Functions 1
Supply Voltage 3.6V
Frequency 2.4GHz
Base Part Number ATBTLC1000
JESD-30 Code R-XXMA-N35
Interface I2C, SPI, UART
Data Rate 1 Mbps
Bandwidth 78MHz
Protocol Bluetooth v4.1
Telecom IC Type TELECOM CIRCUIT
Power - Output 3.5dBm
RF Family/Standard Bluetooth
Antenna Type Integrated, Chip
Sensitivity -95dBm
Number of ADC Channels 1
Serial Interfaces I2C, SPI, UART
Current - Receiving 4.2mA
Current - Transmitting 3mA
Number of GPIO 26
Dimensions
Height 1.868mm
Compliance
RoHS Status ROHS3 Compliant
