XB24-Z7WIT-004

Digi
RoHS
/
Package Module
Category RF/IF and RFID / RF Transceiver Modules
Description DIGI INTERNATIONAL XB24-Z7WIT-004 ZIGBEE MODULE, XBEE ZB, WIRE ANT
PDF
/
Inventory: 4992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Width 24.38mm
Length 32.94mm
Height 2.82mm

Technical

Sensitivity (dBm) -96 dBm
Modulation DSSS
Current - Transmitting 35mA~45mA
Current - Receiving 38mA~40mA
Serial Interfaces UART
Antenna Type Integrated, Wire Antenna
RF Family/Standard 802.15.4
Power - Output 1dBm
Protocol Zigbee?
Utilized IC / Part EM250
Data Rate 250kbps
Number of Channels 15
Frequency 2.4GHz
Voltage - Supply 2.1V~3.6V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series XBee? ZB
Published 2009
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Number of Pins 20
Package / Case Module
Mounting Type Through Hole
Mount Through Hole
