CC1101RGPT

Texas Instruments
RoHS
RoHS RoHS compliant
Package 20-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description RF Transceiver Low-Power Sub-1GHz RF Transceiver
PDF
/
Buying Options
Total Price: USD $5.01
Unit Price: USD $5.0072
≥1 USD $5.0072
≥10 USD $4.4704
≥100 USD $4.023712
≥500 USD $3.665904
Inventory: 916
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-VFQFN Exposed Pad
Number of Pins 20
Weight 69.994973mg

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Type TxRx Only
Subcategory Other Telecom ICs
Voltage - Supply 1.8V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Depth 4.15mm
Frequency 300MHz~348MHz 387MHz~464MHz 779MHz~928MHz
Base Part Number CC1101
Density 0 b
Power - Output 12dBm
RF Family/Standard General ISM < 1GHz
Data Rate (Max) 600kbps
Serial Interfaces SPI
Current - Receiving 14.3mA~17.1mA
Current - Transmitting 12.3mA~34.2mA
Number of Receivers 1
Modulation 2FSK, 4FSK, ASK, GFSK, MSK, OOK
Sensitivity (dBm) -116 dBm

Dimensions

Height 1mm
Length 4mm
Width 4mm
Thickness 930μm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
