MAX7030LATJ+
RoHS
RoHS compliant
RoHS compliantPackage 32-WFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX ISM<1GHZ 32WFQFN
PDF
/
Buying Options
Total Price: USD $8.36
Unit Price: USD $8.35715
≥1 USD $8.35715
≥10 USD $6.8571
≥100 USD $6.64335
≥500 USD $6.42865
≥1000 USD $6.2149
Inventory: 21107
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 32-WFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2012
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 32
ECCN Code EAR99
Type TxRx Only
Terminal Finish Matte Tin (Sn)
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Technology CMOS
Voltage - Supply 2.1V~3.6V 4.5V~5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.7V
Terminal Pitch 0.5mm
Frequency 315MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 32
JESD-30 Code S-XQCC-N32
Qualification Status Not Qualified
Power Supplies 2.5/5V
Supply Current-Max 0.0204mA
Power - Output 13.1dBm
RF Family/Standard General ISM < 1GHz
Sensitivity -114dBm
Data Rate (Max) 66kbps
Current - Receiving 6.4mA~6.7mA
Current - Transmitting 3.5mA~11.6mA
Modulation ASK, OOK
Dimensions
Height Seated (Max) 0.8mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
