HMC545A
RoHS
/
Package SOT-23-6
Category RF/IF and RFID / RF Switches
Description
IC RF SWITCH SPDT 3GHZ SOT26
PDF
/
Buying Options
Total Price: USD $6.58
Unit Price: USD $6.5824
≥1 USD $6.5824
≥10 USD $5.94264
≥100 USD $5.666496
≥500 USD $4.920256
≥1000 USD $4.699094
≥3000 USD $4.284456
Inventory: 181
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
IIP3 54dBm
P1dB 33dBm
Input Power-Max (CW) 34dBm
RF Type WiMax, WLAN
Isolation 22dB
Insertion Loss 0.4dB
Operating Frequency-Max 3000MHz
RF/Microwave Device Type DIVERSITY SWITCH
Frequency Range 0Hz~3GHz
Impedance 50Ohm
Test Frequency 3GHz
Circuit SPDT
Pin Count 6
Base Part Number HMC545
Reach Compliance Code not_compliant
Construction COMPONENT
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Packaging Strip
Operating Temperature -40°C~85°C
Physical
Number of Pins 6
Package / Case SOT-23-6
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
Alternative Model
