DWM1000
RoHS
RoHS compliant
RoHS compliantPackage 24-SMD Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MODULE 802.15.4 CHIP ANT
PDF
/
Buying Options
Total Price: USD $21.48
Unit Price: USD $21.47855
≥1 USD $21.47855
≥10 USD $17.62345
≥100 USD $17.07245
≥500 USD $16.5224
≥1000 USD $15.9714
Inventory: 1187
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Modulation BPM, BPSK
Current - Transmitting 31mA
Current - Receiving 64mA
Serial Interfaces SPI
Antenna Type Integrated, Chip
RF Family/Standard 802.15.4
Telecom IC Type TELECOM CIRCUIT
Protocol IR-UWB
Utilized IC / Part CC1110
Data Rate 6.8Mbps
Frequency 3.5GHz~6.5GHz
Reach Compliance Code unknown
Voltage - Supply 2.8V~3.6V
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 24-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
