TDA7541B
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category RF/IF and RFID / RF Receivers
Description
IC TUNER AM/FM CAR RADIO 64LQFP
PDF
/
Inventory: 5683
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 64-LQFP
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature -40°C~85°C
Packaging Tray
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Automotive Audio
HTS Code 8542.39.00.01
Technology BICMOS
Voltage - Supply 7.7V~9V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 8.5V
Terminal Pitch 0.5mm
Base Part Number TDA7541
Pin Count 64
Operating Supply Voltage 8.5V
Nominal Supply Current 19mA
Input Offset Voltage (Vos) -200mV
Data Interface PCB, Surface Mount
Telecom IC Type TELECOM CIRCUIT
Current - Receiving 48mA
Modulation or Protocol AM, FM
Antenna Connector PCB, Surface Mount
Dimensions
Height Seated (Max) 1.6mm
Length 10mm
Width 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
