RoHS
RoHS RoHS compliant
Package /
Category RF/IF and RFID / RF Multiplexers
Description RF DIPLEXER
PDF
/
Inventory: 1556
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 22.1mm
Length 37.59mm
Height 17.78mm

Technical

Receive Center Frequency 435MHz
Transmit Center Frequency 1000MHz
Insertion Loss (Rx) 1.8 dB
Insertion Loss (Tx) 45 dB
Operating Temperature (Min) -40°C
Physical Dimension L37.59XB22.1XH17.78 (mm)/L1.480XB0.87XH0.7 (inch)
Operating Temperature (Max) 85°C
Reach Compliance Code compliant
Additional Feature IMPEDANCE 75 OHM
Type Diplexer
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Obsolete
Published 2009
Packaging Bulk
