MAX2150ETI+
RoHS
RoHS compliant
RoHS compliantPackage 28-WFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
RF MODULATOR 700MHZ-2.3GHZ 28QFN
PDF
/
Buying Options
Total Price: USD $9.4
Unit Price: USD $9.3974
≥1 USD $9.3974
≥10 USD $7.7102
≥100 USD $7.46985
≥500 USD $7.22855
≥1000 USD $6.9882
Inventory: 1200
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.9mm
Technical
Noise Floor -148dBm/Hz
LO Frequency 700MHz~2.3GHz
RF Frequency 700MHz~2.3GHz
P1dB 1dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Current - Supply 46mA
Output Power -1dBm
Test Frequency 1.75GHz
Temperature Grade INDUSTRIAL
Power Supplies 3/3.3V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Function Modulator
JESD-30 Code S-XQCC-N28
Base Part Number MAX2150
Time@Peak Reflow Temperature-Max (s) 30
Frequency 2.3GHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.7V~3.6V
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tube
Physical
Surface Mount YES
Package / Case 28-WFQFN Exposed Pad
Supply Chain
Factory Lead Time 6 Weeks
