STW82100B
RoHS
RoHS compliant
RoHS compliantPackage 44-VFQFN Exposed Pad
Category RF/IF and RFID / RF Mixers
Description
IC MIXER 1.62-2.4GHZ DWN CONV
PDF
/
Buying Options
Total Price: USD $10.93
Unit Price: USD $10.927267
≥1 USD $10.927267
≥260 USD $4.228851
≥520 USD $4.080493
≥1040 USD $4.006971
Inventory: 1574
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
LO Tunable YES
Number of Mixers 1
Noise Figure 10.5dB
Secondary Attributes Down Converter
Characteristic Impedance 50Ohm
RF Type General Purpose
Gain 8.5dB
Operating Supply Current 108mA
Power Supplies 3.35V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Base Part Number STW82100
Frequency 1.62GHz~2.4GHz
Construction COMPONENT
Voltage - Supply 3.3V~5V
Technology BICMOS
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Packaging Tray
Physical
Number of Pins 44
Surface Mount YES
Package / Case 44-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
