1513349-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category RF/IF and RFID / RF Antennas
Description
Antennas 2.4MHz SB; 802.11 WIMAX U.FL
PDF
/
Buying Options
Total Price: USD $1.48
Unit Price: USD $1.4802
≥1 USD $1.4802
≥10 USD $1.39641
≥100 USD $1.317364
≥500 USD $1.242799
≥1000 USD $1.172455
Inventory: 1161
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Weight 500mg
Technical
Packaging Tape & Reel (TR)
Published 2010
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Applications Bluetooth, WLAN, Zigbee?
Power Rating 10W
Frequency 2.4835GHz
Impedance 50Ohm
Power - Max 10W
Gain 0dBi
Max Frequency 2.4835GHz
Frequency Range 2.4GHz~2.483.5GHz
RF Family/Standard 802.15.4, Bluetooth, WiFi
Antenna Type PCB Trace
VSWR 2
Number of Bands 1
Frequency Group UHF 2GHz~3GHz
Frequency (Center/Band) 2.4GHz
Dimensions
Height 1.57mm
Length 18.034mm
Width 3.7592mm
Height (Max) 0.062 1.57mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
