MAX2321EUP+
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC LNA/MIXER SIGE ADJ 20TSSOP
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6916
≥1 USD $0.6916
≥10 USD $0.5681
≥100 USD $0.55005
≥500 USD $0.532
≥1000 USD $0.5149
Inventory: 1447
Minimum: 1
-
+
Technical Details
Technical
Supply Current-Max 30.8mA
RF/Microwave Device Type DOWN CONVERTER
RF Type CDMA, GSM, PDC, TDMA, WCDMA
Characteristic Impedance 50Ohm
Secondary Attributes With LO Doubler
LO Tunable YES
Down Conversion Gain-Min 9.6 dB
Noise Figure-Max 13.5 dB
Power Supplies 3/3.3V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Function Dual Band LNA/Mixer
Frequency 800MHz~1GHz 1.8GHz~2.5GHz
Construction COMPONENT
Subcategory RF/Microwave Up/Down Converters
HTS Code 8542.39.00.01
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2006
Packaging Tube
Compliance
RoHS Status ROHS3 Compliant
Physical
Surface Mount YES
Package / Case 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
