HMC736LP4ETR
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
VCO Oscillators MMIC VCO ,RF/2, 14.5-15.0GHz
PDF
/
Buying Options
Total Price: USD $47.44
Unit Price: USD $47.43635
≥1 USD $47.43635
≥10 USD $38.92245
≥100 USD $37.70645
≥500 USD $36.4895
≥1000 USD $35.2735
Inventory: 1159
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 4.1mm
Length 4.1mm
Height 1mm
Technical
Secondary Attributes Dual Outputs (Divide by 2, Standard)
RF Type General Purpose
Telecom IC Type TELECOM CIRCUIT
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Function VCO
Base Part Number HMC736
Time@Peak Reflow Temperature-Max (s) 30
Frequency 14.5GHz~15GHz
Terminal Pitch 0.5mm
Supply Voltage 4.2V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Termination SMD/SMT
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
