ELB-2A003
RoHS
/
Package 0805 (2012 Metric), 4 PC Pad
Category Filters / RF Filters
Description
FILTER BAND PASS 5.4GHZ SMD
PDF
/
Inventory: 4761
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric), 4 PC Pad
Technical
Packaging Tape & Reel (TR)
Published 2005
Series ELB2A
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Frequency 5.425GHz Center
Case Code (Metric) 2012
Case Code (Imperial) 0805
Bandwidth 1.05GHz
Filter Type Band Pass
Insertion Loss 1.8dB
Insertion Loss (dB) 1.8 dB
Ripple 1dB
Dimensions
Height 1.2954mm
Length 2.0066mm
Width 1.2446mm
Height (Max) 0.051 1.30mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
