LC72722PM-MPB-E

ON Semiconductor
RoHS
/
Package 24-SOIC (0.311, 7.90mm Width)
Category RF/IF and RFID / RF Demodulators
Description Modulator / Demodulator RDS/RBDS DECODE-IC
PDF
/
Inventory: 2958
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Lifecycle Status OBSOLETE (Last Updated: 1 day ago)

Physical

Mounting Type Surface Mount
Package / Case 24-SOIC (0.311, 7.90mm Width)
Surface Mount YES
Number of Pins 24

Technical

Packaging Tube
Published 2013
JESD-609 Code e6
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 24
Terminal Finish Tin/Bismuth (Sn/Bi)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Subcategory Other Consumer ICs
Max Power Dissipation 175mW
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Qualification Status Not Qualified
Operating Supply Voltage 5.5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 4.5V
Operating Supply Current 9mA
Resolution 4 B
Gain 31dB
Consumer IC Type CONSUMER CIRCUIT

Dimensions

Height Seated (Max) 2.35mm
Length 15.2mm
Width 7.9mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
