ENW-F9202A1EF
RoHS
RoHS compliant
RoHS compliantPackage 51-SMD Module
Category RF/IF and RFID / RF Transceiver Modules
Description
PAN9026, WI-FI DUAL BAND 2.4/5 G
PDF
/
Buying Options
Total Price: USD $30.14
Unit Price: USD $30.141558
≥1 USD $30.141558
≥200 USD $12.027477
≥500 USD $11.62573
≥1000 USD $11.427482
Inventory: 2698
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 51-SMD Module
Technical
Operating Temperature -30°C~85°C
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Voltage - Supply 1.8V~3.3V
Frequency 2.4GHz 5GHz
Interface UART
Data Rate 150Mbps
Utilized IC / Part 88W8977, ENWF9201AZEF, PAN9026
Protocol 802.11a/b/g/n, Bluetooth v5.0
Telecom IC Type TELECOM CIRCUIT
Power - Output 16dBm
RF Family/Standard Bluetooth, WiFi
Antenna Type Integrated, Chip
Sensitivity -98dBm
Serial Interfaces JTAG, UART
Current - Receiving 70mA
Current - Transmitting 400mA
Modulation CCK, DSSS, OFDM
Ambient Temperature Range High 85°C
Dimensions
Height 2.75mm
Compliance
RoHS Status ROHS3 Compliant
