LT5506EUF#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-WQFN Exposed Pad
Category RF/IF and RFID / RF Demodulators
Description
RF DEMOD IC 40MHZ-500MHZ 16QFN
PDF
/
Buying Options
Total Price: USD $9.9
Unit Price: USD $9.9
≥1 USD $9.9
≥10 USD $8.94344
≥100 USD $7.404091
≥500 USD $7.071302
≥1000 USD $6.447355
≥3000 USD $5.615438
Inventory: 251
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-WQFN Exposed Pad
Technical
Packaging Tube
Published 2003
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Voltage - Supply 1.8V~5.25V
Construction COMPONENT
Function Demodulator
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Current - Supply 36mA
Gain 59dB
Operating Frequency-Max 500MHz
Operating Frequency-Min 40MHz
Characteristic Impedance 100Ohm
Noise Figure 6.8dB
RF Frequency 40MHz~500MHz
LO Frequency 80MHz~1GHz
Modulation Technique QUADRAPHASE
Compliance
RoHS Status ROHS3 Compliant
