THS9001DBVT
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category RF/IF and RFID / RF Amplifiers
Description
TEXAS INSTRUMENTS THS9001DBVT AMP, CASCADEABLE, 50350MHZ, SMD, 9001
PDF
/
Buying Options
Total Price: USD $1.22
Unit Price: USD $1.2232
≥1 USD $1.2232
≥10 USD $1.10704
≥100 USD $0.988768
≥500 USD $0.889856
Inventory: 882
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6
Number of Pins 6
Weight 10.007382mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
P1dB 20.6dBm
Noise Figure 4dB
Characteristic Impedance 50Ohm
RF Type Cellular, CDMA, TDMA, PCS
RF/Microwave Device Type WIDE BAND MEDIUM POWER
Gain 15dB
Power Dissipation 463mW
Nominal Supply Current 100mA
Operating Supply Current 100mA
Test Frequency 350MHz
Number of Channels 1
Power Supplies 5V
Operating Supply Voltage 3V
Base Part Number THS9001
Frequency 50MHz~350MHz
Construction COMPONENT
Number of Functions 1
Voltage - Supply 5V
Max Power Dissipation 463mW
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.2mm
Width 1.6mm
Length 2.9mm
Height 1.45mm
