MACP-009596-CA0160
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD Module
Category RF/IF and RFID / RF Directional Coupler
Description
RF DIR COUPLER 5MHZ-1GHZ SM22
PDF
/
Buying Options
Total Price: USD $48.08
Unit Price: USD $48.0833
≥1 USD $48.0833
≥10 USD $39.45255
≥100 USD $38.21945
≥500 USD $36.9873
≥1000 USD $35.7542
Inventory: 1147
Minimum: 1
-
+
Technical Details
Physical
Package / Case 6-SMD Module
Technical
Packaging Cut Tape (CT)
Published 2009
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Frequency 5MHz~1GHz
Operating Temperature (Max) 80°C
Operating Temperature (Min) -20°C
RF/Microwave Device Type DIRECTIONAL COUPLER
Input Power-Max (CW) 23.98dBm
Characteristic Impedance 75Ohm
Insertion Loss (Max) 1.7 dB
Return Loss -16dB
Coupler Type Standard
Coupling Factor 10dB
Compliance
RoHS Status ROHS3 Compliant
