Package 20-SMD Module
Category RF/IF and RFID / RF Amplifiers
Description RF Amplifier 2.4-2.5GHz InGaP HBT Gain 32dB 5Volt
PDF
/
Inventory: 9546
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 6mm
Length 6mm

Technical

RF Type WLAN
Telecom IC Type WIRELESS LAN CIRCUIT
Gain 32dB
Power Dissipation 3.3W
Operating Supply Current 490mA
Test Frequency 2.4GHz
Number of Channels 1
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Pin Count 20
Time@Peak Reflow Temperature-Max (s) 40
Frequency 2.4GHz~2.5GHz
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology BIPOLAR
Max Power Dissipation 3.3W
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish GOLD OVER NICKEL
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Published 2009
Packaging Tape & Reel (TR)

Physical

Weight 123.008581mg
Number of Pins 20
Package / Case 20-SMD Module
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
