HMC313TR
RoHS
/
Package SOT-23-6
Category RF/IF and RFID / RF Amplifiers
Description
RF Amplifier InGaP HBT Gain Block amp SMT, DC - 6 GHz
PDF
/
Buying Options
Total Price: USD $7
Unit Price: USD $7.001696
≥1 USD $7.001696
≥200 USD $2.709826
≥500 USD $2.615297
≥1000 USD $2.568032
Inventory: 7146
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Contact Plating Lead, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6
Number of Pins 6
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature HIGH RELIABILITY
Subcategory RF/Microwave Amplifiers
Max Power Dissipation 259mW
Technology BIPOLAR
Number of Functions 1
Construction COMPONENT
Reach Compliance Code not_compliant
Frequency 0Hz~6GHz
Base Part Number HMC313
Pin Count 6
Operating Supply Voltage 5V
Power Supplies 5V
Number of Channels 1
Test Frequency 0GHz~6GHz
Operating Supply Current 50mA
Gain 17dB
RF/Microwave Device Type WIDE BAND LOW POWER
RF Type WLAN
Input Power-Max (CW) 20dBm
Characteristic Impedance 50Ohm
Noise Figure 6.5dB
P1dB 14dBm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
